| Brand Name : | Shineplus |
| Model Number : | Customized |
| Certification : | ISO13485,ISO9001,UL,ROHS |
| Price : | 1~2$ |
| Payment Terms : | Negotiable |
| Supply Ability : | 8000M/day |
| Delivery Time : | 2~4week |
| MOQ : | 20 M |
Customized mineral fireproof cable BTLY 0.6 1KV 5*16 overhead insulated flexible cable
1.Product description
BTLY cable is a cable with a soft multi-strand construction designed to make laying easier. This mineral fireproof cable is rated at 0.6KV 1kV and is suitable for general power transmission and distribution systems. Its conductor cross-section is 16km2 with 5 cores, making it suitable for a wide range of application scenarios.The BTLY cable has an insulation voltage of 4kV, which ensures the cable's stable operation in high-voltage environments. In addition, the mineral fireproof cable has passed the GB/T 5468-2017 combustion test, indicating that it has good combustion performance. It also meets the fire resistance requirements of the GB 12666.1-2008 standard, ensuring stability in fire situations.
Feel free to contact with us, if you ever needed to consider your
wire harness solution.
Product Name | Customized mineral fireproof cable BTLY0.6 1KV 5*16 overhead insulated flexible cable |
Product certification | Pass ISO13485,ISO9001,UL and ROHS2.0 certification |
Product application | The cable widely use main wire, fire wire, escape and rescue system, such as emergency lighting, fire monitoring, alarm system, elevator system, smoke exhaust system, and control line and other fields |
Temperature | The continuous operating temperature of the bare cable can reach 250℃, and the power supply can last for 3 hours at 950℃~1000℃ |
Color, length | Customized |
Product feature | Flame resistant, UV resistant, halogen free, etc |
Test | Continuity test,flame retardant test |
Free sample | Accept |
Delivery time | 1~2 weeks |
After-sales service | Authentic guaranteed, factory outlets center |
3. Picture of of product
4. Application area
The BTLY cable can be used for power systems for important
buildings and underground works,electrical equipment in factories,
ports and other industrial sites,railways, subways and other
transport infrastructure use electricity,power plant, substation
and other power system engineering and electricity for military
engineering and national defense facilities.
5. Feature
I: Antiseptic insulation: The metal sheath of BTLY insulated
(flexible) mineral insulated refractory cable has this corrosion
resistance. For most devices, no additional protective measures are
required. Even where the metal sheath of the cable is prone to
chemical corrosion or industrial pollution, the cable is still safe
with the protection of plastic outer sheath.
II: High temperature resistance: Short time or extraordinary
period, the mineral fire cable can be close to the melting point of
copper 1083℃ work.
III: Radiation protection, long life: The inorganic materials used
in BTLY cable are radiation resistant, can ensure the stability of
the cable, long life and durability, can be applied to nuclear
power and other fields.
|
|
